INSIGHT S Plus

A high performance long range video feed transmission system.
LONG RANGE
up to 1500 ft in transmission range*
HDMI PORT
in both input and output feed
LOW DELAY
with only 50 microseconds
MULTIPLE FEED
up to 4 video feeds simultaneously
LI-PO POWER
built-in battery for up to 4 hours of usage
REAL-TIME  PREVIEW
with ultra low delays
MULTI-CHANNEL
24 Channels for transmission
REMOTE SHUTTER
control your feeds within a tip of finger
SERIAL PORTS
transfer any data in TTL signal
PWM CONTROL
6 Sets for PTZ or external equipment controls
WIRELESS USB
for data transmission
MULTI-OUTPUT
up to 4 outputs in receiver unit
  • Full Metal Encasement for better heat dissipation

  • Unique Cooling Fin Design

  • High Power top-mount Cooling Fan

  • Micro HDMI Input, suitable for various Camera & Filming Camera

  • Dual TTL Serial Port for External Equipment Control

High Performance Transmitter Design

Features

Insight S Plus

Range

Delay

Frequency

Modulation

Input/Output Interface

Input Video Format

Output Video Format

Compression Ratio

Channels

Supported Device

Operating System

Data Interface

PWM

Encryption

Operating Temperature

Charging Port

Battery

3; 10 Kilometers with High Gain Directional Antenna

70ms

5.1 GHz - 5.8 GHz

OFDM

Mini HDMI & Wi-Fi I/O

4K @ 30 FPS

1080P @ 30 FPS

HEVC 3A HD TV Boardcast Grade

24 Channels

Any devices with HDMI port or 802.11N/AC WIFI

Windows, iOS, Android

5 UARTs

6 sets, supports PTZ and other external equipment

256 AES

-10℃-60℃

USB Type-C 5V

3000 mAH Lithium Polymer Battery

up to 4 hours (Receiver) and 2.5 hours (Transmitter) battery life

Dimensions

Ground Unit

Length

Width

Height

Weight

112.6 mm (116.9mm with SMA Connector)

64.6 mm

31.5 mm

220 g

Sky Unit

Length

Width

Height

Weight

71 mm

33 mm

19 mm (27mm with Fan)

71 g
